Description
The Perfect Gravel Race Machine
The 3T Racemax Italia Red XPLR is for the gravel racer who prioritizes speed above all else. This is a full-aero gravel bike with fully integrated cable routing for speed on-road and off-road, crafted by hand in Italy.
The Racemax is fastest with 700c 35-46mm WAM tires. Built like this, its top speed rivals the best road bikes out there. Whether you're on asphalt, easy or tough gravel, you can be confident that you have the fastest setup on the start line.
Features:
- Perfect Aero Cutout: Close-fitting cutout to shield the rear wheel and achieve the most speed.
- Mind the Gap: No oversized gaps between front tire & downtube for better airflow transition and less turbulence.
- Huge Clearance: The original Exploro set today's standard for up to 54mm tire clearance. The RaceMax has up to 61mm with 650b"!
- 75mm Downtube Base: Lower downtube aero profile is 75mm wide to fully shield the water bottle.
- 50mm Downtube Neck: Upper downtube necks down to 50mm to pick up the airflow coming off the front tire.
- Narrow Headtube: Headtube is sized like a road bike for a narrow 1 1/8"- 1 ¼" steerer for optimal aerodynamics.
- Big Steerer: Inside that narrow headtube is a big 1 1/2" steerer for best strength and stiffness.
- Double-Drop Chainstays: Dropping the drive-side chainstay improves tire & crank clearance. Dropping the other side as well creates a much more efficient structure behind the BB for higher stiffness & strength as well as lower weight.
- Direct-Mount Brake: Standard frames require an adaptor to use a 160mm brake rotor. 3T have integrated that into the frame, meaning you don't need any extra pieces to attach the brake.
- Integrated Fender Mounts: Invisible until you need them. Perfect for 3T custom fenders.
- Self-Aligning Wedge Clamp: Self-adjusting bolt angle for higher clamping forces with lower torque.
- Ritchey Rail Clamp: The new standard for gravel bikes, available for round and oval rails.
Specs*:
- Frame: Racemax Italia Integrale - handmade in Italy, Project X
- Fork: 3T Fango RaceMax Integrale w/ compact crown
- Headset: 3T MinMax Integrale IS42/34 | IS47/38(36deg)
- Thru-Axle: 100x12 front - 142x12 rear
- Handlebar: 3T Aeroghiaia Integrale LTD (51: 40cm - 54&56: 42cm - 58: 44cm)
- Bartape: SRAM Supercork Black
- Stem: 3T More (K-Edge GPS mount included) - (48: 80mm - 51: 90mm - 54:100mm - 56: 110mm - 58: 120mm )
- Rear Derailleur: SRAM Red XPLR eTap AXS D1 12s
- Shift/Brake Levers: SRAM Red D1 AXS 12s
- Brakes: SRAM Red AXS D1
- Rotors: SRAM Paceline CL 160mm F/R
- Crankset: SRAM Force XPLR D2 40T (165mm - 51cm, 170mm - 54cm, 172.5mm - 56cm, 175mm - 58cm)
- Cassette: SRAM Force XPLR XG-1271 12s, 10-44T
- Chain: SRAM Red D1 12s
- Wheelset: Zipp 303 Firecrest
- Tires: Continental Terra Speed 700x40, Amber
- Seatpost: 3T RaceMax Italia Integrale seatpost for Ritchey clamp
- Saddle: Fizik Terra Argo X5 150mm
*Specifications are subject to change without notice
Complete Bicycle Shipping - complete bikes ship to the Continental US (lower 48 states) for a flat rate of $79.99. To get a shipping quote to other locations, add the item to your shopping cart and enter your shipping location.
B-Stock - This product has one or more B-Stock units available. These units can be purchased at a discount (see option select). B-Stock units were returned from other customers and may have missing or damaged packaging materials. These units are otherwise as new. The full manufacturer warranty applies. Click Here for more information.
Please note: This product ships signature required.
